Explosion proof backup camera for fuel tanker, fire truck, coal mining, military application;

Can be fire proof in certain degree, suitable for hard environment and special usage.

If you are looking for such special usage anti explosion camera products or explosion-proof backup cameras manufacturer & supplier in China, Pearl is your first choice.

Product description


1. Use 1/3CMOS sensor, support analog hd video 700TVL
2. Waterproof and explosion-proof
3. Supporting IR-CUT switching to realize day and night monitoring
4. With night vision function, infrared distance is 13m
5. Support mirror switching and ruler control functions

Image Device 1/3 CMOS
Effective Pixels 976(H)*592(V)
Sensing Area 4.880mm*3.670mm
Sync. System Internal
Resolution 700 TVL
Minimum Illumination 0.1 Lux (day), 0 Lux (with IR)
Microphone Optional
Video Output 1.0 Vp-p/75 Ohm
Scanning System interlace
Signal to noise ratio Better than 48dB
White balance AUTO
Gamma Consumption 0.45
Electronic Shutter AUTO
Backlight Compensation AUTO
Power Supply DC12V
Lens 3.6mm
Lens Angle 85°
Current Drain 65±5mA
Operating Temperature -20℃-70℃,RH 95% MAX
Storage Temperature -30℃-80℃,RH 95% MAX




1. Extension cable
2. Adapter cable
3. Power cord
4. RCA adapter
5. Screw package
6. User manual

Explosion Proof Camera System

Explosion Proof Camera System

What is Pearl explosion proof camera system?
Explosion proof Camera System is an integrated rear view security system to help the driver broaden vision and catch the blind spots when driving. It is applicable for the environment which is inflammable, explosive and hazardous. Such as petroleum, chemical, coal, military, medicine, oil storage depots, ships, drilling platforms, gas stations, fireworks production base, food processing and storage factory; particularly suitable for narrow spaces like dangerous goods transport vehicles, oil tanker, chemical laboratories, explosion proof elevator etc.

Why should you choose Pearl explosion proof camera system?
Industrialized design for bad environment such as explosion-proof, anti-corrosion, dust-proof, water-proof and rust-proof needed.
As the third eye of driver to ensure a safe driving and make the reverse parking easier.

Features of Pearl explosion proof camera system
Special Material
Elegant design with the 304 stainless steel electro-polished surface processing, explosion-proof, anti-corrosion, dust-proof, water-proof and rust-proof.

Built-in Infrared LED Lights
IR CUT shifted day and night automatically, the visible distance up to 25 meters, toughened and euphotic explosion-proof glass, flux rate higher than 96%, completely eliminate infrared light halos, high quality image will be showed even in bad light areas.

3D Digital Noise Reduction Technology
Processing the original signal through the 3D digital noise reduction technology so as to make the image vivid and bright at night.

90 Degrees Wide View Angle
Superfine focusing, no distortion and no dark angle with the wide view angle 90 degrees lens, keeping the images clear and authentic.

Waterproof IP67 Monitor
Metal housing waterproof
7 inch digital LCD car monitor 2-ch, 4-ch and 4-ch with quad mode optional
Supports speaker function
